The production process of industrial aluminum powder paste usually includes the following steps:
Raw material preparation: Select suitable aluminum foil scraps or aluminum ingots as raw materials and ensure that their quality meets the requirements. If aluminum foil scraps are used, they need to be screened first, the oxide foils are picked out, and the aluminum foils of different thicknesses are separated to ensure uniform thickness of the raw materials. If aluminum ingots are used, it is necessary to ensure that there are no oxides and the particle size is uniform.
Ball milling: Put the screened aluminum foil or aluminum particles and the aqueous solution with various additives into the ball mill for grinding. During the grinding process, the temperature in the machine should be strictly controlled. If the temperature is too high, it can be adjusted by water cooling. Stop the machine after the material fineness reaches the requirements.
Discharging: After the ball mill stops, immediately add the pre-prepared discharging liquid into the machine, start the machine and run it for 3 to 5 minutes to dilute the material in the machine, and then use vacuum to suck the material into the temporary storage tank. Then use 30 to 50 kg of clean water to rinse the residual material in the machine, and then use vacuum to suck the water into the temporary storage tank.
Dehydration: Place the suction filter in the suction filter tank, then open the discharge valve of the temporary storage tank and place the liquid in the tank into the suction filter tank. When the tank is full, close the valve, start the vacuum pump, open the dehydration valve and the water tank valve, and suck the water into the water tank for recycling. The slurry on the suction filter is unloaded and barreled after the solid content is qualified after inspection.
It should be noted that the production process of industrial aluminum powder paste requires strict control of parameters in each link to ensure the quality and performance of the product. At the same time, safety should also be paid attention to during the production process to avoid accidents.
Raw material preparation: Select suitable aluminum foil scraps or aluminum ingots as raw materials and ensure that their quality meets the requirements. If aluminum foil scraps are used, they need to be screened first, the oxide foils are picked out, and the aluminum foils of different thicknesses are separated to ensure uniform thickness of the raw materials. If aluminum ingots are used, it is necessary to ensure that there are no oxides and the particle size is uniform.
Ball milling: Put the screened aluminum foil or aluminum particles and the aqueous solution with various additives into the ball mill for grinding. During the grinding process, the temperature in the machine should be strictly controlled. If the temperature is too high, it can be adjusted by water cooling. Stop the machine after the material fineness reaches the requirements.
Discharging: After the ball mill stops, immediately add the pre-prepared discharging liquid into the machine, start the machine and run it for 3 to 5 minutes to dilute the material in the machine, and then use vacuum to suck the material into the temporary storage tank. Then use 30 to 50 kg of clean water to rinse the residual material in the machine, and then use vacuum to suck the water into the temporary storage tank.
Dehydration: Place the suction filter in the suction filter tank, then open the discharge valve of the temporary storage tank and place the liquid in the tank into the suction filter tank. When the tank is full, close the valve, start the vacuum pump, open the dehydration valve and the water tank valve, and suck the water into the water tank for recycling. The slurry on the suction filter is unloaded and barreled after the solid content is qualified after inspection.
It should be noted that the production process of industrial aluminum powder paste requires strict control of parameters in each link to ensure the quality and performance of the product. At the same time, safety should also be paid attention to during the production process to avoid accidents.
